Precision ground shaft with grooves for snap rings
Precision ground shaft with grooves for snap rings

Precision ground shaft with grooves for snap rings

Precision ground shaft with grooves for snap ringsThese are precision ground shafts that are made to meet the tight tolerance on the OD, there is a groove on one end for the snap ring, and there is another relief groove for grinding.Part specificationMaterialSteel 1045Size (mm)OD 38 x Length 70Tolerance for key dimension (mm)0/-0.011mm on the ODRoughnessRa0.16-0.32 umCoating:NoneProcessesCNC turning, centerless grindingThe OD is ground to the tolerance of 0-0.011mm by centerless grinding, so as

Views

Views

Precision ground shaft with grooves for snap rings

Interview

Select the number of specifications

Please check the product information you want!

Product Detail


Precision ground shaft with grooves for snap rings

These are precision ground shafts that are made to meet the tight tolerance on the OD, there is a groove on one end for the snap ring, and there is another relief groove for grinding.

Part specification

MaterialSteel 1045
Size (mm)OD 38 x Length 70
Tolerance for key dimension (mm)0/-0.011mm on the OD
RoughnessRa0.16-0.32 um
Coating:None
ProcessesCNC turning, centerless grinding

The OD is ground to the tolerance of 0-0.011mm by centerless grinding, so as to save cost.

No comment

Prev：TS363 SS304 CNC Machining Adapter for Telecommunication Equipment Next：CNC machining aluminum 6061 adapter housing clear anodized
Product Detail


Precision ground shaft with grooves for snap rings

These are precision ground shafts that are made to meet the tight tolerance on the OD, there is a groove on one end for the snap ring, and there is another relief groove for grinding.

Part specification

MaterialSteel 1045
Size (mm)OD 38 x Length 70
Tolerance for key dimension (mm)0/-0.011mm on the OD
RoughnessRa0.16-0.32 um
Coating:None
ProcessesCNC turning, centerless grinding

The OD is ground to the tolerance of 0-0.011mm by centerless grinding, so as to save cost.
